Enterprise Network Architecture

and the OSI Model

Lecture by: Filip Gajic

Introduction

Understanding network fundamentals is crucial for:

Building robust infrastructures
Maintaining enterprise networks
Troubleshooting network issues

The OSI Model

Seven Layers of Network Communication

OSI Model Overview

Physical (Layer 1)
Data Link (Layer 2)
Network (Layer 3)
Transport (Layer 4)
Session (Layer 5)
Presentation (Layer 6)
Application (Layer 7)

Layer 1 - Physical Layer

The Binary Transmitter

Physical transmission of bits
Hardware specifications
Signal and binary transmission

Signal Characteristics

Voltage levels: ±5V
Modulation: Manchester encoding
Clock synchronization
Physical connectors (RJ45, SFP+)

Layer 1 - Physical Layer

Physical Media Types


								# Physical Media Types
								+-------------------+----------------+------------------+
								| Media Type       | Max Speed      | Max Distance     |
								+-------------------+----------------+------------------+
								| Cat5e            | 1 Gbps         | 100 meters       |
								| Cat6             | 10 Gbps        | 55 meters        |
								| Fiber (Single)   | 100 Gbps       | 10 kilometers    |
								| Fiber (Multi)    | 400 Gbps       | 500 meters       |
								+-------------------+----------------+------------------+

Layer 1 - Physical Layer

Python Implementation


									def physical_layer_example():
										"""Physical layer simulation"""
										print("\n=== Layer 1 - Physical Layer Example ===")
										def simulate_binary_transmission(data):
											# Convert string to binary
											binary = "".join(format(ord(i), "08b") for i in data)
											print(f"Original data: {data}")
											print(f"Binary representation: {binary}")
											# Simulate Manchester encoding
											manchester = ""
											for bit in binary:
												if bit == "1":
													manchester += "10"  # 1 becomes 10
												else:
													manchester += "01"  # 0 becomes 01
											print(f"Manchester encoded: {manchester}")

										simulate_binary_transmission("Hello")

Layer 1 - Physical Layer

Output


=== Layer 1 - Physical Layer Example ===
Original data: Hello
Binary representation: 0100100001100101011011000110110001101111
Manchester encoded: 01100101100101010110100101100110011010011010010101101001101001010110100110101010

Layer 2 - Data Link Layer

The Frame Handler

Physical addressing (MAC)
Error detection and correction
Frame delivery


							# Ethernet Frame Structure
							+----------------+----------------+------+----------------+
							| Preamble      | MAC Dest      | MAC  | Payload       |
							| (8 bytes)     | (6 bytes)     | Src  | (46-1500 B)   |
							+----------------+----------------+------+----------------+

Layer 2 - Data Link Layer

Python Implementation


								def data_link_layer_example():
									"""Ethernet frame simulation"""
									print("\n=== Layer 2 - Data Link Layer Example ===")
									def create_ethernet_frame(dest_mac, source_mac, payload):
										# Simulate Ethernet frame structure
										frame = struct.pack(
											"!6s6s2s",
											bytes.fromhex(dest_mac.replace(":", "")),
											bytes.fromhex(source_mac.replace(":", "")),
											b"\x08\x00",  # EtherType (IPv4)
										) + payload
										return frame

									# Example usage
									dest_mac = "00:11:22:33:44:55"
									source_mac = "66:77:88:99:aa:bb"

									payload = b"Sample Ethernet frame payload"
									frame = create_ethernet_frame(dest_mac, source_mac, payload)
									print(f"Ethernet Frame (hex): {frame.hex()}")

Layer 2 - Data Link Layer

Output


=== Layer 2 - Data Link Layer Example ===
Ethernet Frame (hex): 00112233445566778899aabb080053616d706c652045746865726e6574206672616d65207061796c6f6164

Layer 3 - Network Layer

The Traffic Director

Logical addressing (IP)
Routing between networks
Packet forwarding
Traffic control


							# IP Routing Table Example
							Destination     Gateway         Genmask         Flags   Interface
							0.0.0.0         192.168.1.1     0.0.0.0         UG      eth0
							192.168.1.0     0.0.0.0         255.255.255.0   U       eth0
							172.16.0.0      192.168.1.100   255.240.0.0     UG      eth0

Layer 3 - Network Layer

Python Implementation


								def network_layer_example():
									"""IP addressing and routing example"""
									print("\n=== Layer 3 - Network Layer Example ===")
									def get_ip_info():
										try:
											hostname = socket.gethostname()
											ip_address = socket.gethostbyname(hostname)
											print(f"Hostname: {hostname}")
											print(f"IP Address: {ip_address}")
										except socket.gaierror:
											print("Could not resolve hostname to IP")
											print("Using example IP for demonstration")
										# Simulate routing table
										print("\nSimulated Routing Table:")
										routes = [
											{
												"destination": "0.0.0.0/0",
												"gateway": "192.168.1.1",
												"interface": "eth0"
											},
											{
												"destination": "192.168.1.0/24",
												"gateway": "-",
												"interface": "eth0"
											},
											{
												"destination": "10.0.0.0/8",
												"gateway": "192.168.1.254",
												"interface": "eth0"
											}
										]
										for route in routes:
											print(
												f"Dest: {route['destination']:<15} "
												f"Gateway: {route['gateway']:<15} "
												f"Interface: {route['interface']}"
											)

									get_ip_info()

Layer 3 - Network Layer

Output


=== Layer 3 - Network Layer Example ===
Hostname: MacBook-Pro.local
IP Address: 127.0.0.1

Simulated Routing Table:
Dest: 0.0.0.0/0       Gateway: 192.168.1.1     Interface: eth0
Dest: 192.168.1.0/24  Gateway: -               Interface: eth0
Dest: 10.0.0.0/8      Gateway: 192.168.1.254   Interface: eth0

Layer 4 - Transport Layer

The Delivery Manager

End-to-end communication
TCP vs UDP
Port management
Flow control and error handling

Layer 4 - Transport Layer

TCP: Connection-Oriented Protocol

Reliable delivery
Connection establishment
Flow control
Error recovery


							// TCP Connection Example
							socket.connect({
								port: 80,
								host: 'example.com',
								keepAlive: true,
								timeout: 3000
							});

Layer 4 - Transport Layer

UDP: Connectionless Protocol

Fast delivery
No connection needed
No delivery guarantee
Ideal for real-time data


							// UDP Datagram Example
							const dgram = require('dgram');
							const client = dgram.createSocket('udp4');

							const message = Buffer.from('Game state update');
							client.send(message, 0, message.length, 12345, 'gameserver.com', (err) => {
								if (err) console.error('Failed to send packet');
								// No connection state to maintain
								// No delivery guarantee
								// Just fire and forget
							});

Layer 4 - Transport Layer

Python Implementation


								def transport_layer_example():
									"""TCP and UDP socket examples"""
									print("\n=== Layer 4 - Transport Layer Example ===")
									def tcp_server():
										server_socket = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
										server_socket.bind(("localhost", 12345))
										server_socket.listen(1)
										print("TCP Server listening on port 12345")
										return server_socket

									def udp_server():
										server_socket = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)
										server_socket.bind(("localhost", 12346))
										print("UDP Server listening on port 12346")
										return server_socket

									# Example usage
									tcp_sock = tcp_server()
									udp_sock = udp_server()
									print("Transport layer sockets created")

Layer 4 - Transport Layer

Output


=== Layer 4 - Transport Layer Example ===
TCP Server listening on port 12345
UDP Server listening on port 12346
Transport layer sockets created

Layer 5 - Session Layer

The Conversation Controller

Session management
Authentication and authorization
Session recovery & checkpointing


							// Session Establishment Example
							Session.establish({
								type: "NetBIOS",
								authentication: "Kerberos",
								recovery: true,
								checkpointing: {
									interval: "5min"
								}
							});

Layer 5 - Session Layer

Python Implementation


								def session_layer_example():
									"""Simple session management example"""
									print("\n=== Layer 5 - Session Layer Example ===")
									class SessionManager:
										def __init__(self):
											self.sessions = {}

										def create_session(self, user_id):
											session_id = binascii.hexlify(os.urandom(16)).decode()
											self.sessions[session_id] = {
												"user_id": user_id,
												"created_at": time.time(),
												"active": True
											}
											return session_id

										def check_session(self, session_id):
											return self.sessions.get(session_id, {}).get("active", False)

									# Usage example
									session_mgr = SessionManager()
									session_id = session_mgr.create_session("user123")
									print(f"Created session: {session_id}")
									print(f"Session active: {session_mgr.check_session(session_id)}")

Layer 5 - Session Layer

Output


=== Layer 5 - Session Layer Example ===
Created session: 07af8fa6ed9c8d348c9197fb979172a3
Session active: True

Layer 6 - Presentation Layer

The Data Translator

Data translation and encryption
Character encoding (ASCII, Unicode)
Data compression
File formats (JPEG, GIF, MIDI)


							// SSL/TLS Handshake Example
							Client -> Server: ClientHello
							Server -> Client: ServerHello, Certificate
							Client -> Server: ClientKeyExchange
							Both: Generate Session Keys

Layer 6 - Presentation Layer

Python Implementation


								def presentation_layer_example():
									"""Data encryption/decryption example"""
									print("\n=== Layer 6 - Presentation Layer Example ===")

									key = Fernet.generate_key()
									cipher_suite = Fernet(key)

									message = b"Sensitive data to encrypt"
									encrypted_data = cipher_suite.encrypt(message)

									print(f"Original message: {message}")
									print(f"Encrypted data: {encrypted_data}")

									decrypted_data = cipher_suite.decrypt(encrypted_data)
									print(f"Decrypted data: {decrypted_data}")

Layer 6 - Presentation Layer

Output


=== Layer 6 - Presentation Layer Example ===
Original message: b'Sensitive data to encrypt'
Encrypted data: b'gAAAAABnvZ4lgK2gSY3aPk7XKFGFRLA3HuDaD-5BsEN-3pJ4wo0fCabFZDr67zTa9PgEXWrxM-WeYAWVvLD8XDYuU8FTovHiRriyvpUwBWhxP4pqlhx3Ryo='
Decrypted data: b'Sensitive data to encrypt'

Layer 7 - Application Layer

The User Interface Layer

Network applications and services
End-user protocols
Application APIs


							# HTTP Request Example
							GET /index.html HTTP/1.1
							Host: www.example.com
							User-Agent: Mozilla/5.0
							Accept: text/html

Layer 7 - Application Layer

Python Implementation


							def application_layer_example():
								"""HTTP Request using requests library"""
								print("\n=== Layer 7 - Application Layer Example ===")
								try:
									response = requests.get("https://api.github.com")
									print(f"Status Code: {response.status_code}")
									print(f"Headers: {dict(response.headers)}")
								except requests.RequestException as e:
									print(f"Request failed: {e}")

Layer 7 - Application Layer

Output


=== Layer 7 - Application Layer Example ===
Status Code: 200
Headers: {
    'Content-Type': 'application/json',
    'Server': 'GitHub.com',
    'Status': '200 OK',
    'Cache-Control': 'public, max-age=60',
    'Vary': 'Accept, Authorization, Cookie',
    'ETag': 'W/"a0d3712a7766d5f1fc51fcd0dccd709d"',
    'X-GitHub-Request-Id': '5F5D:0000:0000:0000:0000:0000:0000:0000',
    'X-Runtime-rack': '0.024121',
    'X-Content-Type-Options': 'nosniff',
    'X-Frame-Options': 'deny',
    'X-XSS-Protection': '1; mode=block',
    'X-OAuth-Scopes': '',
    'X-Accepted-OAuth-Scopes': '',
    'X-GitHub-Media-Type': 'github.v3',
    'Access-Control-Allow-Origin': '*',
    'Access-Control-Expose-Headers': 'ETag, Link, Location, Retry-After, X-GitHub-OTP, X-RateLimit-Limit, X-RateLimit-Remaining, X-RateLimit-Used, X-OAuth-Scopes, X-Accepted-OAuth-Scopes',
    'Access-Control-Allow-Methods': 'GET, POST, PATCH, PUT, DELETE, OPTIONS',
    'Access-Control-Allow-Credentials': 'true',
    'Strict-Transport-Security': 'max-age=31536000; includeSubdomains; preload',
    'X-Next-Page': 'https://api.github.com/user/repos?page=2',
    'Link': '; rel="next"',
    'Content-Security-Policy': "default-src 'none'",
    'X-OAuth-Client-Id': 'Iv1.a5d5f5d5f5d5f5d5',
    'X-OAuth-Client-Secret': 's5d5f5d5f5d5f5d5f5d5f5d5f5d5f5d5'
}

Network Design Fundamentals

Address Planning


							// Private IP Ranges (RFC 1918)
							10.0.0.0/8     # Large Enterprise
							172.16.0.0/12  # Medium Network
							192.168.0.0/16 # Small Network

Network Design Fundamentals

CIDR Overlap Challenge

Problematic Design ❌


								// Problematic Design ❌
								Development: 10.0.0.0/8
								Staging:     10.0.0.0/8  // Overlap!
								Production:  10.0.0.0/8  // Overlap!

CIDR Overlap Challenge

Optimized Design ✅


								// Optimized Design ✅
								Development: 10.15.0.0/16  // 10.15.0.0 - 10.15.255.255
								Staging:     10.16.0.0/16  // 10.16.0.0 - 10.16.255.255
								Production:  10.17.0.0/16  // 10.17.0.0 - 10.17.255.255

Benefits:

No address space conflicts
Clear separation between environments
Room for expansion

Real-World Example: Enterprise Network Segmentation

Key considerations:

Multiple application services (HeadEndSystem, PaymentHub)
Multiple environments (IaaC, Dev, Staging, Prod)
Integration networks (IPSec, Business Analytics)

Network Range Allocation


								# Application Networks (10.0.0.0/8)

								# HeadEndSystem
								hes-development:        10.4.0.0/16
								hes-development-test:   10.1.0.0/16
								hes-staging:           10.2.0.0/16
								hes-production:        10.3.0.0/16

								# PaymentHub
								payhub-development:     10.5.0.0/16
								payhub-development-test: 10.6.0.0/16
								payhub-staging:        10.7.0.0/16
								payhub-production:     10.8.0.0/16

								# Integration Networks (172.16.0.0/12)

								# IPSec Tunnel
								hes-onomondo-ipsec:    172.16.0.0/24  # VPN connectivity

								# Business Analytics
								hes-ba:               172.16.1.0/24  # Analytics services

Network Design Benefits

Benefits of this design:

Clear separation between applications
Consistent numbering scheme
Reserved ranges for integration services
Room for future expansion

This approach ensures:

No IP range conflicts between environments
Possibility for peering between environments and services
Easy identification of traffic sources
Simplified network security policies

Network Design Fundamentals

Network Range Strategy

10.0.0.0/8 for main applications
- Each environment gets a /16 block
- Sequential allocation for easy management
172.16.0.0/12 for integration services
- Smaller /24 blocks for specific services
- Clear separation from main application traffic
192.168.0.0/16 reserved for future use

Azure Virtual Network Architecture


								module "vnet" {
									source              = "../../../1_modules/network"
									vnet_name           = "VirtualNetwork"
									location            = local.location
									resource_group_name = local.resource_group_name
									address_space       = [local.address_space]

									subnets = {
										"default" = {
											address_prefixes = ["${local.address_prefix}.0.0/24"]
										}
										"app-gateway" = {
											address_prefixes = ["${local.address_prefix}.1.0/24"]
										}
										"database-subnet" = {
											address_prefixes = ["${local.address_prefix}.2.0/24"]
											service_endpoints = ["Microsoft.Storage"]
											service_delegation = {
												name = "Microsoft.DBforPostgreSQL/flexibleServers"
												actions = [
													"Microsoft.Network/virtualNetworks/subnets/join/action"
												]
											}
										}
									}
								}

Cloud Infrastructure

Azure Networking with Terraform

Azure Network Infrastructure


								# Basic VNet Configuration
								module "vnet" {
									source = "../modules/network"
									vnet_name = "VirtualNetwork"
								}

Subnet Strategy


								subnets = {
									"default" = {
										address_prefixes = ["${local.address_prefix}.0.0/24"]
									}
									"app-gateway" = {
										address_prefixes = ["${local.address_prefix}.1.0/24"]
									}
									"dlms-db-subnet" = {
										address_prefixes = ["${local.address_prefix}.2.0/24"]
										service_endpoints = [
											"Microsoft.Storage"
										]
										service_delegation = {
											name = "Microsoft.DBforPostgreSQL/flexibleServers"
											actions = [
												"Microsoft.Network/virtualNetworks/subnets/join/action"
											]
										}
									}
									"container-apps" = {
										address_prefixes = ["${local.address_prefix}.6.0/24"]
										service_delegation = {
											name = "Microsoft.App/environments"
											actions = [
												"Microsoft.Network/virtualNetworks/subnets/join/action"
											]
										}
									}
								}

Security and Compliance

Network Security Implementation


							// Network Security Group Rule Example
							{
								"name": "allow-https",
								"priority": 100,
								"direction": "Inbound",
								"access": "Allow",
								"protocol": "Tcp",
								"sourcePortRange": "*",
								"destinationPortRange": "443",
								"sourceAddressPrefix": "*",
								"destinationAddressPrefix": "VirtualNetwork"
							}

Monitoring and Operations

Performance Metrics
Bandwidth Utilization
Latency Monitoring
Proactive Alerting


							monitoring:
							  metrics:
								- bandwidth_utilization
								- latency
								- packet_loss
								- error_rate
							  alerts:
								- threshold: 80%
								  metric: bandwidth
								  action: notify_team

Key Takeaways

OSI model is your framework
Design for scalability
Avoid CIDR overlaps
Build-in security
Monitor proactively

Q&A (🍻 Time)

Thank you for your attention and let's grab a beer while discussing your questions.

Muzika

Stoja feat. Dejan Matić
